AnalysIR supports PSOC 4 from Cypress

AnalysIR now provides support for the PSOC 4 Prototyping kit from Cypress. Effective immediately users of AnalysIR can use the kit to act as an Infrared source for AnalysIR. The PSOC 4 Prototyping kits are available from Cypress and via their global distributors for just US$4 plus shipping. To use the kit with AnalysIR you will also need an IR Receiver and an optional IR Learner, which can also be purchased with AnalysIR. Initially, the PSOC Firmware is available on request and will be included as part of the installation package in a future release.

PSOC4 and AnalysIR
PSOC4 and AnalysIR

Continue reading AnalysIR supports PSOC 4 from Cypress

Teensy now supported for AnalysIR

A new user of AnalysIR from the Netherlands, wanted to get the AnalysIR firmware working on Teensy 3.x . Although this has not been officially supported, we were happy to support his efforts knowing that it would most likely be a relatively easy exercise, based on past experiences. Needless to say, he was successful in decoding Infrared signals with AnalysIR within a short space of time. Prompted by his interest, we ordered our own Teensy 3.1 to add to our growing collection of 40+ MCUs and although Teensy support is in beta for now, it will be oficially supported for AnalysIR from our next release. In the meantime, users of AnalysIR can just contact us for a copy of the Teensy sketch (firmware).

Teensy 3.1 now supported for AnalysIR
Teensy 3.1 now supported for AnalysIR

Teensy 3.x now joins a long list of devices supported for use with AnalysIR, including: Continue reading Teensy now supported for AnalysIR

Raspberry Pi, AnalysIR & LIRC serve-up Infrared Remote Control

We have been intending to add support for LIRC into AnalysIR for a long time. Recently one of our enthusiastic users, working on his Raspberry PI,  needed some help getting Air conditioner signals from his ‘Air Conditioner’ infrared remote control decoded. His preference was for a LIRC based approach as he already had this working for his TV via his RPi using a cool web based interface from his smart phone.

Rasberry Pi tight integration with AnalysIr and  LIRC
Rasberry Pi tight integration with AnalysIr & LIRC

Continue reading Raspberry Pi, AnalysIR & LIRC serve-up Infrared Remote Control

Latest ‘New Year’ release of AnalysIR with full support for USB IR Toy and more.

Dublin, Ireland – 31st January 2014. We are happy to announce the latest ‘New Year’ release of AnalysIR to all our backers & supporters. Since the completion of the crowd-funding campaign on Indiegogo we have added over 125 updates and enhancements to AnalysIR, with more to come.

AnalysIR Screenshot
AnalysIR Screenshot

A major highlight of this release is full AnalysIR support for USB IR Toy from Dangerous Prototypes (V1 & V2 hardware) for decoding and resending IR signals at all common modulation frequencies. In our opinion, AnalysIR is now the premier GUI supporting DP’s IR toy, not to mention the Arduino, RPi, MSP430 F5529 LaunchPad (beta)  and more. A selection of enhancements in this latest release, include: Continue reading Latest ‘New Year’ release of AnalysIR with full support for USB IR Toy and more.

Testing AnalysIR with a custom PCB

Here are some photos we captured, of a sample of our MCU test rigs and custom PCB for AnalysIR.

AnalysIRtestrigs
A sample of our test rigs for AnalysIR

The photo above shows some of our test setup for Arduino, Raspberry Pi, TI MSP430 LaunchPad and the (big) baby of them all the USB IR Toy. The small red custom PCBs are ones we had made via Elecrow which worked out great. So instead of just using  solderless breadboards we now plug these ‘half shields’ directly into the Arduino header, or in the case of the RPi using a ribbon cable. The USB IR Toy already has the IR receivers on board and doesn’t require this PCB.

We should also be able to hook up the LaunchPad to this board using headers. So once we receive the full set of headers, we ordered on-line, we will have all our test setups much neater and more reliable. Previously, we used solderless breadboards, as can be seen in the photo attached to the LaunchPad. Continue reading Testing AnalysIR with a custom PCB

USB IR Toy – test release issued.

Today we issued a test release of AnalysIR, supporting V1 & V2 USB IR Toy loaded with firmware V22. If you have an IR Toy and want to test it out, leave a message with your email in the contact form at the top. Naturally, this is available only to backers with AnalysIR. You can support our project and get a copy of AnalysIR via the option at the top of this page.

Continue reading USB IR Toy – test release issued.

AnalysIR integrated support for USB IR Toy

Dangerous Protoypes
USB IR Toy V2 from Dangerous Prototypes (via Seedstudio)

We received a V2 USB IR Toy last week from Dangerous Prototypes via Seedstudio.
(See early access note for backers below)

After some initial teething problems we set about playing with this new device. Then we went about trying to integrate it into AnalysIR. We found that operating the IR Toy in ‘Sampling Mode’ worked best for our needs. There are several other modes available which are described on the website below. Continue reading AnalysIR integrated support for USB IR Toy

SKY+ IR remote codes

We are working on a project to create a custom TV remote to control a SKY+ satellite box, for a friend who cannot manage the standard remote control or even the accessibility ones that are available.

SKY+ Remote Control

Continue reading SKY+ IR remote codes

Update: AnalysIR Phase 1 roll-out, Arduino Due

Just a quick update to let you know how things are progressing with the phase 1 roll-out.

Today we have issued our 2nd release to the initial participants which includes 22 updates and fixes to AnalysIR plus many other updates to the User Guide. AnalysIR has benefited greatly from the feedback received with a bonus of more features added.

We have recently received an Arduino DUE and have succeeded in porting our existing Arduino code to this new device. The porting was surprisingly quick and very few changes were required, which is all credit to the Arduino Team for making it so easy for us. The DUE code will be merged into our release cycle sometime over the next month or so.

So far we have had mainly positive results on the Arduino platform. However, the Raspberry Pi platform (RPi) is presenting more challenges than anticipated. The good news is that we believe we have a workaround for RPi and we will work on resolving any trailing issues over the next weeks. Another aspect of the RPi roll-out is that it requires greater knowledge of things such as Linux, networking and compiling on the RPi for users. We will put some thought and effort into trying to simplify this experience – but this may take more time than anticipated. Arduino is just so easy to use…..

At this time, we would also like to open up the phase 1 roll-out to another 10 backers on a first come basis. So the first 10 emails to arrive in our inbox, from backers, will receive an invitation. You can use the IGG message feature for this or just email info@A?????IR.com (replace the A?????IR with our name). To participate you will need an Arduino or RPi and an IR receiver and of course time.

At this point we still expect to release AnalysIR to all backers in or around Sep 30th.

Finally, many thanks again for all your support and patience.

Campaign completes successfully at 208% of Target & 150 Backers

Wow, what a couple of months this has been with over 1,300 emails received, new partners, over 4,168 referrals to the campaign, 208% funded, several world firsts with IR on Arduino & Raspberry Pi and most importantly backed by 150 people from 32 Countries across the globe. Not to mention some great bonus features added to AnalysIR along the way, some of which have been inspired by our backers.

Our tasks for the next week include, progress on the following:

– Documentation
– Installation Package for download
– Some bug fixing
– Online bug tracker
– Online discussion board
– Web site
– Select & Issue email Invitations to 1st phase roll-out participants
– Ship remaining kits.

I would like to finish up this update by welcoming our latest backers and thanking all our backers for your support.

The AnalysIR Team
