AnalysIR integrated support for USB IR Toy

Dangerous Protoypes
USB IR Toy V2 from Dangerous Prototypes (via Seedstudio)

We received a V2 USB IR Toy last week from Dangerous Prototypes via Seedstudio.
(See early access note for backers below)

After some initial teething problems we set about playing with this new device. Then we went about trying to integrate it into AnalysIR. We found that operating the IR Toy in ‘Sampling Mode’ worked best for our needs. There are several other modes available which are described on the website below. Continue reading AnalysIR integrated support for USB IR Toy

Custom TV remote control using Arcade style console

  Following on from our previous blog post about SKY+ RC6 IR codes, we have now completed the project and are about to ship to its new owner – a friend of ours.

SR1We purchased a Sega megadrive Arcade style games console which was BNIB for €25 ($35) and disabled all of the built-in gaming functionality. We then wired up each of the 12 available switches (Joystick & Arcade style buttons) to the Arduino Nano which was placed onto an Arduino prototyping shield and mounted to the enclosure using ‘lots’ of hot glue. Note some of these consoles come with an additional 2 buttons, which can bring the total to 14. In addition, the joystick has 8 positions in total of which we used only 4 as it would be too difficult for the user to manage all eight. Continue reading Custom TV remote control using Arcade style console
