Tag Archives: Air Conditioner

Latest release of AnalysIR V1 preview #3 is now available for download

Dublin, Ireland – 27th August 2015. We are happy to announce the latest release of AnalysIR V1 preview #3 is now available for download by our backers & supporters. Existing users of AnalysIR will receive an email with instructions on how to download this version. New users will receive the details as part of the registration process.

AnalysIR Screenshot
AnalysIR Screenshot

A major highlight of this release is full AnalysIR support for our soon to be released A.IR shield. A.IR was designed to function as a high-end input/otput IR device for AnalysIR and will also work with IRremote, IRLib and any other Arduino sketch. More details will be published soon.

View the AnalysIR Product Sheet(PDF)

We would like to extend a big thanks to the many users around the world who have helped with feature requests, new protocols and testing over the past 2 years.

Some Highlights in this latest release include:

Continue reading Latest release of AnalysIR V1 preview #3 is now available for download

Simple Infrared PWM on Arduino, Part 2- RAW IR Signals

In Part 1 of this series, we demonstrated how to send signals using simple Infrared PWM on Arduino. In this Part 2 post we look at sending RAW IR signals – specifically a RAW NEC signal and a longer RAW Mitsubishi Air Conditioner signal. We have also improved the method shown in Part 1 due to some issues we identified when sending ‘real’ signals versus the ‘test’ signal we used before. (More on that later). In Part 3, we will take the signals from this post and show how to send them using their binary (or Hex) representation, which saves lots of SRAM.

Original NEC 32-bit and Mitsubishi 88-bit Signals displayed using AnalysIR
Original NEC 32-bit and Mitsubishi 88-bit Signals displayed using AnalysIR

Continue reading Simple Infrared PWM on Arduino, Part 2- RAW IR Signals

Simple Infrared PWM on Arduino

We are often asked on discussion boards, about conflicts between IRremote or IRLib and other Arduino Libraries. In this post, we present a sketch for ‘Simple Infrared PWM on Arduino’. This is the first part in a 3 part series of posts. Part 1 shows how to generate the Simple Infrared PWM on Arduino (AKA carrier frequency), using any available IO pin and without conflicting with other libraries. Part 2 will show how to send a RAW infrared signal using this approach and Part 3 will show how to send a common NEC signal from the binary or HEX value.

Example 56kHz generated Infrared signal @ 50% duty cycle
Example 56 kHz generated Infrared signal @ 50% duty cycle

Continue reading Simple Infrared PWM on Arduino

Latest release of AnalysIR V1 preview #2 is now available for download

Dublin, Ireland – 17th April 2015. We are happy to announce the latest release of AnalysIR V1 preview #2 is now available for download by our backers & supporters. Existing users of AnalysIR will receive an email with instructions on how to download this version. New users will receive the details as part of the registration process.

AnalysIR Screenshot
AnalysIR Screenshot

A major highlight of this release is full AnalysIR support for our soon to be released LearnIR (IR Learner). LearnIR delivers the best performance available for receiving and sending Infrared signals with excellent accuracy.

View the AnalysIR Product Sheet(PDF)

We would like to extend a big thanks to the many users around the world who have helped with feature requests, new protocols and testing over the last months.

Some Highlights in this latest release include:

Continue reading Latest release of AnalysIR V1 preview #2 is now available for download

Reverse engineering the Mitsubishi AC Infrared protocol

This post is the second in a two-part series about Reverse Engineering AC Infrared protocols. This time we look at the Mitsubishi Air Conditioner IR Protocol. The project was undertaken by  two of our users in France (Vincent & Mathieu), with the help of AnalysIR, who  collaborated to reverse engineer this Mitsubishi and previously the Panasonic AC Infrared protocol, both examples of the more challenging AC Infrared protocols. Not only did they identify the individual field codes & checksum but also provided some impressive documentation. Detailed information is available via GitHub which is linked below. This 288 data bit Mitsubishi AC Infrared protocol is composed of two consecutive frames. Both frames are always identical for each signal sent. In common with most AC units the complete settings are sent with every IR signal (temperature, fan, swing etc…). AnalysIR was used to record and turn the signal into HEX/Binary format from which the reverse engineering of the individual fields was tackled.

Mitsubishi AC AnalysIR Screenshot
Mitsubishi AC AnalysIR Screenshot

Continue reading Reverse engineering the Mitsubishi AC Infrared protocol

Reverse engineering the Panasonic AC Infrared protocol

Recently, two of our users in France (Vincent & Mathieu) collaborated to reverse engineer the Panasonic AC Infrared protocol, one of the more challenging AC Infrared protocols using AnalysIR. Not only did they identify the codes & checksum but also provided some impressive documentation and full source code to help others. Detailed information is available via GitHub which is linked below. This 216 data bit Panasonic AC Infrared protocol is composed of two consecutive frames. The first frame remains constant for every command sent to the AC unit. In common with most AC units the complete configuration is sent with every IR signal (temperature, fan, swing etc…). AnalysIR was used to record and turn the signal into HEX/Binary format from which the reverse engineering of the individual fields was tackled.

AnalysIR - Panasonic AC 216 bit Infrared signal
AnalysIR – Panasonic AC 216 bit Infrared signal

Continue reading Reverse engineering the Panasonic AC Infrared protocol

Preview: DetectIR, advanced infrared receiver

The fourth member of our MakeIR series of devices & kits will be DetectIR. This infrared receiver module can be configured for Visual IR signal detection, Serial over IR or as an Infrared receiver which can handle even the longest Air conditioner signals. DetectIR is built with only the highest quality IR components available.

DetectIR block diagram
DetectIR block diagram

We have provided a link below to the preliminary product data sheet and would welcome feedback on additional, nice to have or missing features, if any. Please read the datasheet for a more detailed description of DetectIR. Continue reading Preview: DetectIR, advanced infrared receiver

Video: AnalysIR Demo Batch Infrared Decoding

Here we show a screen capture demonstration of the ‘Batch Decoding’ feature of AnalysIR. We show Infrared signals from 4 different Air Conditioners and how we can load them into AnalysIR and execute a batch decode of all of the signals in one easy step. Included are signals from Panasonic, Vestel, Fujitsu & Daikin

Continue reading Video: AnalysIR Demo Batch Infrared Decoding

AnalysIR now decodes 40 Infrared Protocols

We have been updating the AnalysIR documentation for the upcoming 1.0 release and realised that AnalysIR now decodes 40 Infrared protocols. Wow!. Along with the most common TV & media remotes controls there are 15 Air Conditioner protocols included. The full set of protocols is included with the latest ‘dev’ release, which is available to all current & new owners of AnalysIR (less the aforementioned documentation) in advance of the  pending 1.0 release. The 1.0 release will incorporate over 170 new features, updates and fixes compared to the initial release and also supports our new IR Learner which will be launched along with a range of Infrared kits in the coming months.

Over 40 Infrared ProtocRols supported by AnalysIR
Over 40 Infrared Protocols supported by AnalysIR

Here is the latest list of Infrared protocols supported by AnalysIR. Continue reading AnalysIR now decodes 40 Infrared Protocols

Controlling Chigo Air Conditioner via Infrared from smart phone

Anyone who has tried  controlling an Air Conditioner unit using an Arduino, USB IR Toy, RPi or any MCU will know how difficult it can be to record the longer infrared signals they use. Typical TV systems use IR signals circa 32 bits long, while this Chigo AC unit uses a signal with 197 marks & spaces (or 97 data bits). One of our users, Sertunc – from Istanbul in Turkey, reported his success using AnalysIR to easily record the signal timings for his AC unit and sent us the details along with some nice photos. After testing the validity of the recorded signals using an Arduino, he then set about loading the signals onto his Samsung smart phone (models S4, s4 mini, S5 and more supported). This was helped by installing the free ‘Samsung IR – Universal Remote‘ app onto his phone via Google Play.

Samsung IR Remote appSamsung IR Remote app

Continue reading Controlling Chigo Air Conditioner via Infrared from smart phone
